35kV Porcelain Housed ZnO Lightning Arrester Y5WZ5-51/134

35kV Porcelain Housed ZnO Lightning Arrester Y5WZ5-51/134

35kV Porcelain Housed ZnO Lightning Arrester Y5WZ5-51/134

MOQ: 10
Price: 1
Detail Information
Product Description
Detail Information
Certification:
ISO9001
Model NO.:
Y5WZ5-51/134
Installation Type:
Parallel Arrester
Operation Voltage:
High Voltage
Shape:
Spiral
Material:
ZnO
Arc-Extinguishing Medium:
Air
Housing Material:
Porcelain
System Voltage:
35kv
Nominal System Voltage:
35
Rated Voltage:
51
Continuous Operating Voltage:
40.8
Minimum Reference Voltage:
73
High Current Impulse:
65
Line Discharge Class:
1
Weight:
55 Kg
Highlight:

35kV porcelain lightning arrester

,

ZnO substation arrester Y5WZ5-51/134

,

high voltage lightning arrester with warranty

Product Description
35kV Porcelain Housed Gapless Metal Oxide Lightning Arrester (Y5WZ5-51/134)
Product Specifications
Attribute Value
Model NO. Y5WZ5-51/134
Installation Parallel Arrester
Application Substation
Size Large
Operation Voltage High Voltage
Shape Spiral
Material ZnO
Arc-Extinguishing Medium Air
Housing Porcelain
Accessories Surge Counter
System Voltage 35kV
Transport Package by Wood Carton
Specification SGS
Trademark YongDe
Origin China
HS Code 85354000
Production Capacity 100PCS/Month
Product Images
35kV Porcelain Housed ZnO Lightning Arrester Y5WZ5-51/134 0 35kV Porcelain Housed ZnO Lightning Arrester Y5WZ5-51/134 1 35kV Porcelain Housed ZnO Lightning Arrester Y5WZ5-51/134 2 35kV Porcelain Housed ZnO Lightning Arrester Y5WZ5-51/134 3 35kV Porcelain Housed ZnO Lightning Arrester Y5WZ5-51/134 4 35kV Porcelain Housed ZnO Lightning Arrester Y5WZ5-51/134 5
Key Features
  • Double sealing structure with core encapsulated by molded silicone rubber for complete sealing solution
  • Two-way pressure release structure for enhanced safety
  • ZnO varistor core component with excellent pressure ratio consistency, large flow capacity, and high reliability
  • Wide creepage distance suitable for III level heavy pollution areas
Technical Specifications
Type Nominal System Voltage Rated Voltage Continuous Operating Voltage MRV under 1/5 μs Steep Discharge Current MRV under 8/20 μs Lightning Discharge Current MRV under 30/60 μs Operating Discharge Current Minimum Reference Voltage under 1 mA DC 4/10 μs High Current Impulse Twice (KA) 2mS SW through-flow capacity A/18 Line Discharge Class Weight kg
Y5WZ5-51/134 35 51 40.8 154 134 114 73 65 150 400 1 55
MRV means Maximum Residual Voltage
35kV Porcelain Housed ZnO Lightning Arrester Y5WZ5-51/134 6
